1/4" X 1-1/8" X 2" U-Bolt w/ MP Zinc
Item Number: 502207
$2.05
/ Each
Package Quantity:
1
- Round bend U-bolt sized for 3/4" nominal steel or wrought iron pipe. 1/4"-20 NC rolled thread. Anchors pipe, conduit, tubing, round bar, cable or rope to a flat surface.
- Inside 1-1/8" x 2", outside 1-5/8" x 2-1/4", 1" of thread on each leg.
- Zinc plated steel. Plate 3/4" x 2" x 1/16". Two hex nuts included.
- Thread 1/4"-20 UNC, NC rolled, 1" of thread on each leg
- Inside 1-1/8" wide x 2" deep; overall 1-5/8" wide x 2-1/4" long
- Mounting plate 3/4" wide x 2" long x 1/16" thick, low carbon cold rolled steel with rounded edges
- Supplied with mounting plate and two hex nuts
- Zinc plated for corrosion resistance
- Fits 3/4" nominal steel or wrought iron pipe (1.050" OD)
- Includes mounting plate and two hex nuts - ready to install
- Zinc plated low carbon steel for corrosion resistance
$2.05
/ $2.05 Each
In Stock
Details
Vendor
Chicago Hardware (1231)
Weight (lbs)
0.1
Thread Size
1/4"-20 UNC
Thread Length (TL)
1"
Inner Dimensions (ID)
1/4" X 1-1/8" X 2"
Overall Dimensions (OD)
1/4" X 1-5/8" X 2-1/4"
Plate Dimensions (P)
1/16" X 3/4" X 2"
For Pipe Size
3/4" nominal
Bend Type
Round Bend
Material
Low Carbon Steel
Finish
Zinc Plated
Includes
U-bolt, mounting plate, 2 hex nuts
Key Features
- Fits 3/4" nominal steel or wrought iron pipe (1.050" OD)
- Includes mounting plate and two hex nuts - ready to install
- Zinc plated low carbon steel for corrosion resistance
- 1/4"-20 NC rolled threads, 1" of thread on each leg
- Round bend profile for pipe, conduit, tubing, round bar and cable
